Large-Scale Evaporative Condenser Manufacturers

Working Principle of Evaporative Condenser

Application Cases of Evaporative Condenser

1. Food Processing Industry: Providing cooling support for the quick-freezing production line of Wufeng Food, Kaidi's evaporative condenser controls the condensing temperature of the refrigeration system below 36℃, with a daily heat load handling capacity of 2500kW, helping the production line achieve stable 24-hour continuous operation and saving more than 800,000 kWh of electricity annually.
2. Pharmaceutical Industry: Serving the raw material drug production workshop of Shanghai Pharmaceuticals, customized corrosion-resistant condensing coils are developed for the cooling needs of chemical reactors, meeting the strict requirements of pharmaceutical production for equipment cleanliness and stability, and the equipment has been running without failure for three consecutive years.
3. Cold Chain Logistics Industry: Equipping the refrigeration system of GLP cold chain warehousing with evaporative condensers, which maintain stable condensing pressure even in high-temperature and high-humidity environments, ensuring that the temperature of the warehousing space is constantly kept below -18℃ and guaranteeing the quality of cold chain goods.



Comparison Between Evaporative Condenser and Traditional Cooling Equipment

Key Maintenance Points of Evaporative Condenser

1. Daily Maintenance: Check the fan operation sound and spray uniformity daily, and clean up debris in the water tank; monitor the pH value (maintained between 7.0-8.5) and turbidity of cooling water weekly to ensure water quality meets standards.
2. Regular Maintenance: Clean the dehydrator and spray nozzles monthly to avoid clogging; inspect the corrosion condition of condensing coils every six months and conduct rust removal and anti-corrosion treatment; thoroughly clean the water tank and coils every year to remove scale and sediments, and Kaidi provides professional on-site maintenance services.
3. Winter Maintenance: Drain all water from the equipment during long-term shutdown, turn off the power supply and do a good job of thermal insulation to prevent pipe freezing and cracking; check the circuit system and sealing performance before restarting.

   Frequently Asked Questions (FAQ)

1. What is the applicable temperature range of Kaidi's evaporative condenser?

   Kaidi's evaporative condenser has a wide applicable temperature range, from -10℃ to 45℃. In low-temperature environments, the anti-freezing function can be activated by starting the heating device to prevent water freezing; in high-temperature and high-humidity environments, the heat exchange efficiency is guaranteed by optimizing the ventilation structure. Equipment versions resistant to extreme temperatures can be customized for special working conditions.
2. Does the electronic descaling equipment need regular replacement of consumables?

   No, it doesn't. Kaidi's electronic descaling equipment adopts a consumable-free design, with the service life of core components exceeding 10 years. Only regular cleaning and parameter calibration are needed to maintain stable descaling effect, which greatly reduces the maintenance cost.
3. What are the advantages of using the evaporative condenser and electronic descaling equipment together?

   The combined use of the two can form a closed-loop system of "cooling + anti-scaling". The electronic descaling equipment can effectively prevent the scaling of condenser coils, avoid the decline of heat exchange efficiency and equipment corrosion, extend the maintenance cycle and service life of the evaporative condenser, reduce the frequency of chemical cleaning, and lower the overall operation cost. The comprehensive energy efficiency of the system is increased by more than 25% compared with using the evaporative condenser alone.
4. Can the company provide customized product solutions?

   Yes, it can. Kaidi has a professional R&D team and a standardized laboratory. It can customize the coil material and structural size of the evaporative condenser according to the customer's industry characteristics and working condition parameters (such as heat load, water volume, water hardness, etc.), as well as the processing power and installation method of the electronic descaling equipment. At the same time, it provides complete pre-design calculation and on-site commissioning services.
